Designing an Accessory Dwelling Unit (ADU): A Structural Guide covers the engineering decisions that sit underneath every backyard cottage, basement apartment, or converted garage in Colorado. An ADU is a small, self-contained dwelling on the same lot as a primary house, and because it is a dwelling, it must carry the same gravity, snow, wind, and seismic loads as the main home while also meeting the egress, fire-separation, and ceiling-height rules of the International Residential Code (IRC). This guide explains what each ADU type means structurally, which foundation systems suit Colorado’s frost depth and expansive clay soils, how roof framing is sized for Front Range and mountain snow loads, how plumbing and egress openings change the load path, what a structural permit set contains, and which mistakes show up most often on ADU projects.
Looking for an ADU structural engineer rather than a guide? ISTA Engineers prepares PE-stamped, permit-ready ADU structural plans for Colorado homeowners, builders and architects. Call (720) 740-4060 to talk through your project.
Why Designing an Accessory Dwelling Unit (ADU) Starts With a Structural Guide
A successful ADU project represents more than additional square footage. It is an engineered living space that must stand on its own foundation, resist the same environmental loads as the primary house, and pass plan review by a building department that treats it as a full dwelling. According to the International Building Code (IBC) Section 310.1, ADUs must comply with specific requirements for foundation design, including a minimum foundation depth of 12 inches below the finished grade. That baseline is only the start in Colorado, where local amendments push footings far deeper to clear the frost line and where soil reports frequently change the foundation type entirely.
In Denver, the zoning laws and regulations for ADUs are outlined in the Denver Zoning Code, which requires that ADUs be designed and constructed in accordance with the International Residential Code (IRC). Zoning sets the envelope: maximum size limitations (typically 800 square feet or 50% of the primary dwelling’s square footage), height limits, and setbacks. Those limits feed directly into structural design. A height cap can force a low-slope roof that collects more drifting snow, and a tight rear setback can place a new footing within a few feet of an existing garage foundation, which changes how both footings are detailed. Jurisdictions such as Aurora, Lakewood, Boulder, and Colorado Springs each adopt the IRC with their own amendments, so the structural guide for an ADU has to be read against the specific municipality.
ADU Types and What Each Means Structurally
ADUs fall into four structural categories: detached new construction, attached additions, garage conversions, and basement units. The label matters because it determines whether the engineer is designing a complete new load path from roof to soil or evaluating an existing one and reinforcing it. A detached unit requires every structural element to be new. An attached unit shares a wall, a roof plane, or a foundation with the main house. A conversion inherits a structure that was never designed for residential occupancy.
A common planning question is whether a detached or attached ADU is the better choice. The answer depends on lot geometry, existing structure condition, and budget. Detached ADUs offer design freedom and privacy but typically cost more because of independent foundation and utility systems. Attached ADUs may lower construction cost but introduce structural integration work, since the new unit’s loads must be traced through walls, beams, and footings that were sized for a different purpose. The sections below outline what each type demands from the structural design.
Detached ADU Structural Design
A detached ADU, often called a backyard cottage or carriage house, functions as an independent one- or two-story structure with its own foundation, lateral system, and roof. Engineers size the footings from the geotechnical report, specify wall framing (commonly 2×6 studs at 16 inches on center to accommodate Colorado energy-code insulation), design roof trusses or rafters for the local snow load, and detail the shear walls and hold-downs that resist wind and seismic forces. Two-story detached units above a garage add floor-vibration and beam-depth considerations, and the garage door opening below typically requires a portal frame or steel moment frame to maintain lateral resistance.
Because nothing is borrowed from the primary house, a detached unit is the most predictable ADU type to engineer. The trade-off is site work: new utility trenches, a new foundation excavation to frost depth, and drainage grading away from both the ADU and the existing house. Engineers also check the clearance between the new footing and any adjacent structure so that excavation does not undermine a neighboring garage slab or fence footing. For a ground-up unit, the firm’s New Construction Design process applies in miniature: soils, foundation, gravity framing, lateral framing, and connection details, each stamped for permit.
Attached ADU Structural Design
An attached ADU, whether a rear addition, a side wing, or a unit over an attached garage, must connect to the existing house without overloading it. The engineer identifies which existing walls become bearing walls for the new roof, whether the existing foundation can accept added load, and how the new roof ties into the old one so that snow does not pile in a valley over an undersized rafter. Fire separation between units is a structural detail as well as a code one: IRC Section R302.3 requires a one-hour fire-resistance-rated assembly between dwelling units, and the wall or floor-ceiling assembly chosen affects stud depth, sheathing, and connection detailing.
Differential settlement is the quiet risk in attached designs. A new footing poured next to a decades-old foundation will settle at a different rate, so engineers often dowel the new footing into the old one or deepen the new footing to match the existing bearing elevation. Where a new door or hallway cuts through an existing exterior wall, a header or beam must carry the roof load that wall previously supported. These reinforcement and load-transfer tasks fall under Structural Modification Design, and they are the reason an attached unit can be structurally more involved than a detached one despite being smaller.
Garage Conversion and Basement ADU Structural Considerations
Garage conversions and basement ADUs reuse an existing shell, so the engineering centers on evaluation rather than new design. An existing garage foundation is frequently not designed to support the weight of a residential structure, in which case a new foundation that meets local building codes and regulations may need to be designed. Garage slabs are typically unreinforced or lightly reinforced and poured at grade, which leaves them below the floor-elevation and insulation requirements of a dwelling. The full set of requirements is covered in the dedicated garage to adu conversion article, so this guide treats only the structural outline.
Basement ADUs raise ceiling height and egress issues first and foundation issues second. IRC Section R305.1 requires a minimum habitable ceiling height of 7 feet, and many Front Range basements fall short, which leads to underpinning or slab lowering. Cutting a new egress window into a foundation wall removes concrete that was resisting soil pressure, so the opening needs a reinforced lintel and often a new window well with a drain. Before any of this is drawn, a Foundation Inspection establishes whether the existing walls show heave, horizontal cracking, or moisture intrusion that would make the conversion impractical without repair.
ADU Foundation Options in Colorado
The foundation is the component most likely to be changed by site conditions, so ADU foundation requirements receive the most scrutiny in Colorado plan review. The appropriate foundation type depends on soil conditions, ADU size, and whether the unit is attached or detached. Options range from concrete slab-on-grade to crawlspace or basement foundations, with pier-and-beam and post-tensioned slabs used where soils are poor. In Denver’s clay-rich soils, which are prone to expansion and contraction, special consideration must be given to foundation depth and reinforcement.
Most Front Range jurisdictions require a geotechnical report for a new foundation, and the report’s swell-consolidation test results drive the choice. Low-swell sandy soils in parts of Thornton and Westminster can accept a conventional spread footing. High-swell claystone and bentonite layers common in southeast Denver, Aurora, and the Douglas County edge call for drilled piers with void forms under grade beams, or a post-tensioned slab that can flex as a unit. The report also provides the allowable bearing pressure the engineer uses to size footings, so no responsible ADU foundation design proceeds without it.
Slab-on-Grade vs. Pier-and-Beam ADU Foundations
A slab-on-grade foundation places the ADU floor directly on compacted fill with thickened edges or perimeter footings carrying the walls. It is the least expensive system and the fastest to build, and on stable soils it performs well for single-story detached units. In expansive soils, a plain slab cracks and heaves as moisture changes; engineers respond with a structurally reinforced slab, a post-tensioned slab, or a slab isolated from the walls so that heave does not lift the framing. Moisture control around the slab, including roof drainage discharged at least 5 feet from the foundation and positive grading, is part of the structural design rather than an afterthought.
A pier-and-beam foundation, by contrast, lifts the floor on wood or steel beams spanning between drilled concrete piers or spread footings, leaving a crawlspace below. The crawlspace provides utility access, which simplifies plumbing for a unit with a kitchen and full bath, and the piers can be drilled past the active clay zone to bedrock or stable strata. The cost is higher and the floor framing must be designed for live load and deflection like any residential floor. Pier-and-beam is the usual answer when a soils report shows high swell potential or when the lot slopes enough that a level slab would require significant fill.
Frost Depth and Expansive Soils for ADU Foundations in Colorado
Frost depth sets the minimum footing elevation. The IRC requires footings to extend below the frost line, and Denver’s building code amendments set that depth at 36 inches below finished grade, with mountain jurisdictions requiring 42 inches or more. A footing that stops short of this depth is exposed to frost heave, where freezing water in the soil expands and lifts the foundation unevenly. The 12-inch minimum described earlier applies only where frost is not a concern, which is nowhere in Colorado.
Where both frost depth and soil expansion are concerns, an engineer may specify a reinforced slab with deepened perimeter footings, an approach intended to help avoid the cracking issues commonly seen in DIY ADU projects. The deepened perimeter satisfies frost depth, while the reinforcing steel lets the slab bridge soft spots and resist differential movement. On high-swell sites, the geotechnical engineer may recommend overexcavating 2 to 3 feet of native clay and replacing it with moisture-conditioned fill, or may call for drilled piers that bypass the clay altogether. Each of these choices appears on the stamped foundation plan with rebar size, spacing, and concrete strength specified.
ADU Framing and Roof Design for Colorado Snow Load
Snow load controls roof design across Colorado. The structural components of an ADU are scrutinized because inspectors need to verify that the design accommodates Colorado’s snow loads, wind requirements, and seismic considerations. Denver’s amendments set a 30 pounds per square foot design roof snow load, Boulder matches it, and foothill and mountain towns such as Evergreen, Nederland, and Breckenridge require substantially higher values, often 75 psf and above. ASCE 7-22 Chapter 7 governs how ground snow load converts to roof load and how drift surcharges are added where a low ADU roof sits next to a taller house wall.
Drifting is the detail most often missed on ADU roofs. An attached unit with a flat or low-slope roof below the main house eave collects windblown snow against the step, and the surcharge at that line can double the uniform load over several feet of roof. Engineers size the rafters or trusses in that zone separately and check the bearing wall and header below it. For roof framing, pre-engineered wood trusses at 24 inches on center are the common choice for detached units, while attached units with irregular geometry are more often stick-framed with 2×10 or 2×12 rafters and a structural ridge beam. Wall framing follows the IRC braced-wall provisions in Section R602.10 or an engineered shear-wall design, with hold-down anchors at panel ends and continuous load paths from roof sheathing to foundation anchor bolts.
How Utilities and Egress Affect ADU Structure
Utilities and egress openings interrupt structure, so they are coordinated on the structural drawings rather than left to the trades. A full kitchen and bathroom require a 3- or 4-inch waste line with slope, which in a slab-on-grade ADU means trenching through the slab before the pour or, in a conversion, saw-cutting an existing slab and repairing the reinforcing. Water heaters, furnaces, and mini-split condensers add concentrated loads to floors or roofs and need blocking or a dedicated pad. Running a new electrical service or gas line from the primary house to a detached unit crosses the yard in a trench that must not undermine either foundation.
Egress rules shape wall and foundation openings. IRC Section R310 requires every sleeping room to have an emergency escape and rescue opening with a minimum net clear area of 5.7 square feet, a minimum clear height of 24 inches, a minimum clear width of 20 inches, and a sill no higher than 44 inches above the floor. In a wood-framed wall this means a wider header; in a basement foundation wall it means cutting reinforced concrete and installing a lintel sized for the soil load above. Stairs to a second-floor or basement ADU need stringers, landings, and guard posts detailed to IRC Section R311, and the floor opening for a stair removes joists that must be headed off and supported. Each of these openings is drawn on the framing plan with its header or lintel size so that the lateral system still closes.
What Does an ADU Structural Permit Set Contain?
An ADU structural permit set contains a stamped foundation plan with footing sizes, reinforcing, and anchor bolt layout; floor and roof framing plans showing member sizes, spacing, headers, and beams; a lateral design showing shear wall or braced wall locations with hold-downs; typical and specific connection details; general structural notes listing design loads, material strengths, and referenced codes; and structural calculations supporting those drawings. Building departments also expect the companion documents a complete submittal requires, including site plans, foundation details, framing plans, and energy compliance calculations, along with the geotechnical report where one is required.
The structural sheets are typically labeled S0 through S4: S0 for general notes and design criteria, S1 for the foundation plan, S2 for the floor framing plan, S3 for the roof framing plan, and S4 for sections and details. Plan reviewers check design loads against the jurisdiction’s adopted snow, wind, and seismic values, confirm footing depth against local frost depth, and verify that any existing structure being reused was evaluated. Professional structural engineering services typically represent 1-3% of the total project cost, and for most ADU projects in Denver, structural engineering fees range from $2,000 to $5,000, depending on the complexity, size, and whether the unit is attached or detached. A breakdown of what drives that range is in the adu structural engineering cost article.
What Engineers Commonly See When Designing an Accessory Dwelling Unit (ADU)
The same handful of problems recurs across ADU projects regardless of city. Foundations designed without a soils report are the first. A builder prices a standard spread footing, the geotechnical report later identifies high-swell claystone, and the foundation budget changes after the permit application is in. Shallow footings on garage conversions are the second. Many older Denver garages sit on a turned-down slab edge 12 to 18 inches deep, well above the 36-inch frost line, so the conversion cannot proceed as a simple interior remodel.
Roof framing is the third pattern. Low-slope roofs added against a taller house are sized for uniform snow and not for drift, and headers over wide openings such as a garage door or a sliding patio door are undersized for the point loads delivered by trusses above. Lateral design is the fourth. Small structures with large glazing areas on one side often lack enough solid wall length for a prescriptive braced-wall solution, and the plan arrives at review without hold-downs or a shear-wall schedule. A Structural Inspection of an existing garage or basement before design starts resolves most of these questions early, because it establishes footing depth, wall condition, and framing sizes before any drawing is produced.
Common Mistakes in ADU Structural Planning
Skipping the existing-structure evaluation is the most costly mistake. Owners converting a garage or basement frequently assume the shell is sound because it has stood for decades, but the loads of a dwelling with a full bath, kitchen, insulated roof, and occupancy differ from those of a parking space. Another frequent error is treating egress and utilities as finish items. A bedroom egress window added after framing is complete requires reframing a header, and a waste line routed after the slab is poured requires cutting concrete that was designed to remain continuous.
Mismatched foundation elevations between new and existing work also cause problems. A new ADU footing poured at a different bearing depth than the adjacent house footing settles differently, which opens a crack at the connection line within the first few seasons. Finally, roof-to-wall connections are often drawn generically. Colorado wind speeds along the Front Range require rafter or truss uplift connectors at every bearing point, and Boulder sits in a special wind region with higher design speeds, so a connector schedule copied from a plan set drawn for another state will not pass review.
Designing an Accessory Dwelling Unit (ADU): Key Structural Takeaways
An ADU is a complete dwelling in a small footprint, and its structural design follows the same sequence as a house: soils report, foundation sized to frost depth and swell potential, gravity framing sized for Colorado snow, lateral framing sized for wind and seismic, and openings for egress and utilities coordinated on the plans. Detached units demand a full new load path. Attached units and conversions demand an honest evaluation of what already exists. The foundation decision between slab-on-grade, pier-and-beam, and reinforced or post-tensioned systems is almost always dictated by the geotechnical report rather than by preference.
The engineers at ISTA Engineers prepare these structural designs for ADUs throughout the Denver metro area and across Colorado as part of the firm’s Residential Structural Engineering Services. Homeowners, architects, and builders who have settled on an ADU type and need stamped foundation, framing, and lateral drawings for permit can contact the firm for a consultation.
